MIDEA SPLIT AC MSIAF09CRDN2X

General Specification


Model Indoor

MSIAF-09CRDN2X(I)

Model Outdoor

MSIAF-09CRDN2X(O)

Power Supply (V,Hz,Ph)

220-240V,1Ph,50Hz

Capacity (Btu/h)

9.000

Indoor Dimension (WxDxH) mm

715x194x285

Outdoor Dimension (WxDxH) mm

720x270x495

Net Weight (Kg)

Indoor 7.4 | Outdoor 21.1

EER (W/W)

3.54

Rated Current

5.1 A

Air Flow

508/406/330 m3/H

Noise Level (dBA)

Indoor 39.5/34/29.5| Outdoor 53

Compressor

Model: KSK103D33UEZ3 | Type: ROTARY

Refrigerant Type

R32

Pipe Length (M)

25

Height Differences (M)

10

Pipe Size Liquid (mm-inch)

6.35mm(1/4in)

Pipe Size Gas (mm-inch)

9.52mm(3/8in)

Temperature Range (°C)

17~30

Warranty


Compressor

10 Years

Sparepart & Service
